    Bra Tapes Continuous Dyeing Machine Price

    Short Description:

    Basic Info Model NO.: KW-807-SJ-400-A Warranty: 1 Year Customized: Customized Condition: New Machine Type: Dyeing&Finishing Machine Driven Type: Electric Power(W): 32kw Phase: 3 Phases 50/60Hz Working Linest: 1-8 Lines Heating System: Electrical/Steam Max Working Temperature: 180-220 Maximum Speed (M): 35-40 M/Min Drying Type: Hot Air/Natural Gas Boiler Application: Elastic Tapes,Polyester Tapes,Polyester Webbings Trademark: KINWAH Transport Package: Full Container or Less Container ...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    Product Tags

    Basic Info

    Model NO.: KW-807-SJ-400-A
    Warranty: 1 Year
    Customized: Customized
    Condition: New
    Machine Type: Dyeing&Finishing Machine
    Driven Type: Electric
    Power(W): 32kw
    Phase: 3 Phases 50/60Hz
    Working Linest: 1-8 Lines
    Heating System: Electrical/Steam
    Max Working Temperature: 180-220
    Maximum Speed (M): 35-40 M/Min
    Drying Type: Hot Air/Natural Gas Boiler
    Application: Elastic Tapes,Polyester Tapes,Polyester Webbings
    Trademark: KINWAH
    Transport Package: Full Container or Less Container with Plastic Film
    Specification: CE certification
    Origin: Dongguan, Guangdong
    HS Code: 894560000

    Product Description

    Bra Tapes Continuous Dyeing Machine PriceItem No:KW-807-SJ-400-A
    Size:15000mm *5000mm * 1800mm
    This is updated newest polyester+elastic tapes continuous dyeing and finishing machineFeatures:
    1)with PLC
    2)with  J-Box/Feed in.
    3)our patents.
    4)it’s the best seller in 2013 .
    5)laid out a new system of tension automatic control
    6)Application: The dyeing machine is especially used for dyeing nylon elastic tapes(elastic bands,elastic shoulder tapes etc) into any color and polyester elastic tapes into light color laces.

    Item
    Heat System electrical steam
    Working Width(mm) 200 400 600
    Thermofixation Chamber Tape Content(m) 45/60 80/90
    Maximun Speed(m) 15 30 35
    Maximun Number(m) 4 8 12
    Control system Manual/PLC

    Option: J-Box  Feed in device with individual tapes tension control
    Processes: J-Box-Feed in-dyeing groove-Steam chamber-washing tank-Pre-dryer-chemical groove-drying&finishing unit-take off
    Options:manual control,PLC(touch screen)control,feed in device with individual tapes tension control.
    Our Services
    Customers: SATIN RIBBONS, ELASTIC TAPES continuous dyieng and finishing
    machines: MONTRIMS,ITL,GLOBAL LABEL, KINGS, LEADER,XINLIN,SANDING GROUP,
    BRAITEX, TELALA, WARRANTY, APEX, N R GROUP, SHORE TO SHORE, KNITTING
    CONCERN, STRETCHLINE, DUGOTEX SO ON.

    Company Informatio
    KIN WAH Mechanical Industrial Co., Ltd. established in the year of 2005, has been dedicated in researching and developing KIN WAH dyeing and finishing equipment series for narrow fabric for more than twenty years. KIN WAH dyeing and finishing equipment series include High temperature Continuous Dyeing & finishing Machines, Normal temperature Continuous Dyeing &finishing Machines, High & Normal Temperature Continuous Dyeing & finishing Machines (same machine), Finishing & Starching Machine, Calender Machine for labels, packaging machines, rolling machines and relative narrow fabric Complete Plant programming. They are widely used for all kinds of narrow fabric made from polyester, nylon and cotton material, such as automobile seat belts (one end & two-ends), heavy duty tapes, textile lift slings, safety belts, luggage & bag belts, satin ribbons, ornament ribbons, labels, elastic tapes, organza tapes, curtain tapes, and cotton tapes.

    Packaging & Shipping
    Covered by plastic membrane within full container or less container
    (woodencase)
