    European Standrd seatbelt webbings continuous dyeing and finishing machine Factory

    Short Description:

    MODEL NO.:KW-800-AQS200 This is a kind of High Speed European Standard Single End Automobile Seatbelt/safety webbings continuous dyeing and finishing machine. Single End High speed With Elongation with Calender function With Computer Our Patent. High efficinecy 1)Application: The dyeing machine(with PLC) is especially used for dyeing single-end type Automobile Seatbelt/Safety webbing with European standard requirement.with elongation and relative calender function. 2)Processes: Feed in →J-BOX...


  • Product Name: Disposable Face Mask
  • Product Feature: High Protect, Safe, Fit & Comfort
  • Product Implementation Standards: Q/Jlm 01-202
  • Carton Dimension: 455*385*435mm
  • Paper Box Size: 185*110*85mm
  • Mask Package: 40PCS/Paper Box
  • Box Packag: 50box/Carton, 2000PCS/Carton
  • Full Carton Weight: 8.89kg
  • Product Detail

    Product Tags

    MODEL NO.:KW-800-AQS200

    This is a kind of High Speed European Standard Single End Automobile Seatbelt/safety webbings continuous dyeing and finishing machine.

    Single End

    High speed

    With Elongation

    with Calender function

    With Computer

    Our Patent.

    High efficinecy

    1)Application: The dyeing machine(with PLC) is especially used for dyeing single-end type Automobile Seatbelt/Safety webbing with European standard requirement.with elongation and relative calender function.

    2)Processes: Feed in →J-BOX →Accumulator →dyeing padder→Hot Air Chamber→Hold mangle→Thermosal  Chamber→Heavy duty CalenderPull Mangle→Chemical padder→Hot Steam ChamberWashing tankHot Air ChamberCool SystemChemical padder→Infrared PredryingHold mangle→Final hot air chamber→Heavy duty CalenderPull Mangle→Cool System→Take off

    3)Production capacity:1 pcs/time,0-70meter/min/pcs. or 2PCS/time, 0-30meter/ min/pcs.

    4)thermofixiation chamber webbing content:240meters/70meter.

    2)Production capacity:1-12pcs/time,0-35meter/min/pcs.

    Heat System electrical  |LPG or natural gas  |steam
    Working Width(mm) 200
    Thermofixation Chamber Tape Content(m) 240
    Maximun Speed(m) 70
    Maximun Number(m) 1
    Control System Computer control( PLC & Touch screen)
    Elongation Rate 5% Minimum, 19% Maximum
