Elastic Tapes Continuous Dyeing Machine with High Quality

Short Description:

Basic Info Model NO.: KW-807-SJ400 Warranty: 1 Year Customized: Customized Condition: New Machine Type: Dyeing&Finishing Machine Driven Type: Electric ...

Send email to us Download as PDF

Product Detail

Product Tags

Basic Info

Model NO.: KW-807-SJ400

Warranty: 1 Year

Customized: Customized

Condition: New

Machine Type: Dyeing&Finishing Machine

Driven Type: Electric

Phase: 3 Phases

Frequency: 50/60Hz

Power(W): 55kw

Dimension(L*W*H): 18000mm * 1000mm* 4000mm

Weight: 5000kg

Max Speed: 40m/Min

Pre-Drying Type: Infrared

Drying Type: Hot Air

Trademark: KINWAH

Transport Package: Wooden Box

Specification: CE certification

Origin: Dongguan, Guangdong

HS Code: 84514000

Product Description

elastic tapes continuous dyeing machine with High quality

Item No:KW-806-SJ400-A
Size:15000*2400*1000mm
This is updated newest elastic tapes continuous dyeing machine

Features:
1)with PLC
2)with J-Box.
3)our patents.
4)it’s the best seller in 2013 .
5)laid out a new system of tension automatic control
6)Application: The dyeing machine is especially used for dyeing nylon elastic tapes(elastic bands,elastic shoulder tapes etc) into any color and polyester elastic tapes into light color laces.

Item
Heat System	electrical	steam
Working Width(mm)	200	400	600
Thermofixation Chamber Tape Content(m)	45/60	80/90
Maximun Speed(m)	15	20	30
Maximun Number(m)	4	8	12
Control system	Manual/PLC

Option: J-Box Feed in device with individual tapes tension control

Processes: J-Box-Feed in-dyeing groove-Steam chamber-washing tank-Pre-dryer-chemical groove-drying&finishing unit-take off

Options:manual control,PLC(touch screen)control,feed in device with individual tapes tension control.
