Factory wholesale Automatic Label Silkscreen Printing Machine - Cargo Harness Webbing Continuous Dyeing Machine – Kin Wah

Item No:KW-820-DZ400

Size:    16800*1000*4000mm

This is high speed Sling webbings/tie down straps/lash straps continuous dyeing&finishing machine

Application: The dyeing machine is especially used for dyeing textile lift slings,tie down straps,lash straps and Heavy duty belts with elongation.

Product capacity: 1-4 Pcs/time, 0-15meter/min/Pcs

Can dye both 350mm width sling webbings,heavy duty webbings,tie down straps,lash straps,etc.

With strong elongation function.

For 300mm width webbings:1 meter go into dyeing machine,1.02meter come out after dyed.

For 50mm width webbings:1 meter go into dyeing machine,1.06meter come out after dyed.

Heat System       electrical/LPG or natural gas

Working Width(mm)        600

Thermofixation Chamber Tape Content(m) 60

Maximun Speed(m)   20

Maximun Number(m)   8

Control system       Computer control

Processes: Feed in-dyeing groove-Infrared pre drying-hold mangle-

thermofixation-cooling system-pull mangle-take off
