    Single End 200mm Safety Belts Continuous Dyeing and Finishing Machine

    Short Description:

    Basic Info Model NO.: KW-800-AQS200 Warranty: 1 Year Customized: Customized Condition: New Machine Type: Dyeing&Finishing Machine Main Part Materials: Stainless Steel,Iron,Carbon Steel etc ...


    Product Detail

    Product Tags

    Basic Info

    Model NO.: KW-800-AQS200
    Warranty: 1 Year
    Customized: Customized
    Condition: New
    Machine Type: Dyeing&Finishing Machine
    Main Part Materials: Stainless Steel,Iron,Carbon Steel etc
    Power: 38kw
    Driven Type: Electric
    Phase: 3 Phases
    Frequency: 50/60Hz
    Max Speed: 40m/Min
    Heating System: Electrical&LPG or Natural Gas
    Drying Type: Hot Air
    Max Working Temperature: 220°c
    Trademark: KINWAH
    Transport Package: Full Container or Less Container with Plastic Film
    Specification: CE certification
    Origin: China
    HS Code: 84514000

    Product Description

    Single end 200mm safety belts continuous dyeing and finishing machine

    Item No: KW-800-AQS200
    Size:    15000*1000*1800mm
    This is high speed luggage&Suitcase belts/webbing continuous dyeing machines for nylon webbings,and polyester webbings,safty webbings,lanyard ribbons,harness webbings and heavy duty webbings etc.

    Features:
    1) High efficiency
    2) Power Energy Saving
    3) Our patents.

    4)Application: The dyeing machine is especially used for
    luggage&Suitcase belts/webbing continuous dyeing machines
    for nylon webbings,and polyester webbings,safty webbings,lanyard ribbons,harness webbings and heavy duty webbings with thickness below 1.5mm.

    5)Product capacity: 1-12 Pcs/time, 0-35meter/min/Pcs.

    Heat System       electrical/LPG or natural gas/steam
    Working Width(mm)  200/400/600
    Thermofixation Chamber Tape Content(m) 45/60/60/80
    Maximun Speed(m)   15/30/40
    Maximun Number(m)  6/10/20
    Control system        Manual/Computer control(PLC&Touch screen)

    Processes: Feed in-dyeing groove-Infrared pre drying-thermofixation chambers-chemical groove-steam chamber-washing tanks-chemical groove-hot air chamber drying&finishing unit-cooling system-take off

    Customers: SATIN RIBBONS, ELASTIC TAPES continuous dyieng and finishing machines: MONTRIMS,ITL,GLOBAL LABEL, KINGS, LEADER,XINLIN,SANDING GROUP, BRAITEX, TELALA, WARRANTY, APEX, N R GROUP, SHORE TO SHORE, KNITTING CONCERN, STRETCHLINE,  DUGOTEX SO ON.

    KIN WAH Mechanical Industrial Co., Ltd. established in the year of 2005, has been dedicated in researching and developing KIN WAH dyeing and finishing equipment series for narrow fabric for more than twenty years. KIN WAH dyeing and finishing equipment series include High temperature Continuous Dyeing & finishing Machines, Normal temperature Continuous Dyeing &finishing Machines, High & Normal Temperature Continuous Dyeing & finishing Machines (same machine), Finishing & Starching Machine, Calender Machine for labels, packaging machines, rolling machines and relative narrow fabric Complete Plant programming. They are widely used for all kinds of narrow fabric made from polyester, nylon and cotton material, such as automobile seat belts (one end & two-ends), heavy duty tapes, textile lift slings, safety belts, luggage & bag belts, satin ribbons, ornament ribbons, labels, elastic tapes, organza tapes, curtain tapes, and cotton tapes.

    Package:Covered by plastic membrane within full container or less container (woodencase)
